●Patent integrated design The patented integrated design of the controller and the hydraulic cylinder greatly improves the convenience of the maintenance and inspection of the controller;
●Patented handle head design Integrated dual-start handle head design with emergency braking function, which is more flexible for two-hand control;
●Safe and stable emergency power-off switch, powerful driving wheel protective cover;
●Easy to operate The handle head is designed with full consideration of ergonomics, and each function button is convenient and easy to operate; the built-in charger makes charging more convenient.
Model | Unit | EPT1.5 | ||
Parameters | Drive unit | Electric | ||
Load Capacity | Kg | 1500 | ||
Load center | mm | 600 | ||
Brake way | 電磁失電制動 | |||
Wheels and tyres | Tyre type | Polyurethane | ||
Front tyre dimensions | mm | φ80×70 | ||
Traction wheel | mm | φ210×70 | ||
Wheels quantity front/rear(x=traction) | 1x-4/1 | |||
Dimensions | Travel position tiller height | mm | 700-1000 | |
Fork lift height | mm | 115 | ||
Forks clearance from the ground | mm | ≤80 | ||
Fork dimensions Forks size | S/L1/E (mm) | 1178×160×53 | ||
Total length | mm | 1275 | ||
Total width | mm | 550 | ||
Minimum turning radius | mm | 1400 | ||
Performance | ||||
Traction speed(lade/unlade) | Km/h | 4.6/4.2 | ||
Maximum grade ability (lade/unlade) | ％ | 6/3 | ||
Weight | Truck weight (without battery) | Kg | 115 | |
Motors Battery | electrical engineering control system | 直流 | ||
Traction motor | KW | 0.65 | ||
Battery volts/ampere | V/Ah | 24V/25Ah | ||
Battery Charger | Input | AC V/Hz | 220V/50(60)HZ | |
Output | DC V/A | 24V/10A | ||
